AEROJIB

Industry Standard Fixed Arm Jib

4'-8" to 10'

Variable Reach

110LBS

Max Payload

11'-4"

Max Height

THE GOLD-STANDARD

The Aerojib is the gold-standard for fixed-arm jibs. Modular builds allow the crane to be built from 4'-8" to 9’-8". The Aerojib mounts on a standard Mitchell or Euro/Elemac, and is simple to build safely in less than 15 mins. Four-way leveling head included.



The crane uses any secure Mitchell platform as a base. Run it on a Chapman or Fisher dolly on the nose or center-post kit, or use one of Treefort’s mobile base options.

MODULAR BUILDS

Reach: Length from Fulcrum to Mitchell Nose

Total Length: From Bucket to Mitchell Nose

Max Height: Length from ground to Mitchell Nose at maximum tilt (47°) with the fulcrum 4' feet off the ground.

Max Payload: Maximum weight on Mitchell Nose

CONFIGURATION
REACH
TOTAL LENGTH
MAX HEIGHT
MAX PAYLOAD
X-Short
4'-8"
7'-3"
7'-10"
110 LBS
Short
5'-8"
8'-3"
8'-6"
110 LBS
Medium
6'-8"
9'-3"
9'-2"
110 LBS
Long
8'-8"
13'-3"
10'-8"
110 LBS
X-Long
9'-8"
14'-3"
11'-4"
110 LBS

SETUP & TRANSPORT


Transports in a

TRUCK OR VAN

TreefortIcon_Case (1).png

Weight of case:

382 LBS

Full crane contained in

1 CASE + 1 WEIGHT CART

TreefortIcon_Clock (2).png

First time using an Aerojib?

COME BY FOR A DEMO

Sets up in

15 MINUTES

PAIR IT WITH...

Compatible with Mitchell or Euro mounts!

ef6827_6824a765c4a940ae9574693a478d261f~mv2 (1).webp

Sturdy and highly maneuverable base with option of pneumatic or stage wheels. Can also be used on dolly track for dynamic moves.

GFM Crane Base

Grip Factory Munich


Treefort’s Mobile Base is a flexible way to move jibs and cranes around on location with ease. This base can also go on dolly track.

Mobile Jib Base

Treefort

AeroJibSpecSheet (1).png

CHECK OUT OUR SELECTION OF HEADS

The MoSys L40 is a lightweight 2-axis head for high-end digital cinematography, ideal for camera packages up to 88 lbs. Includes backpan compensation.

Mo-Sys

L40

Lightweight, 3-axis stabilized remote head that allows users to capture stable imagery in the most demanding environments for camera packages up to 50lb.

Freefly

MOVI-XL

Extremely stable remote head with true motion control capability. Ideal for camera packages up to 50 lbs.

RavensClaw

TALON

The Lambda 25 is a 2 or 3-axis nodal head with versatile mounting options, 360° rotation, and smooth fluid control for highly precise shots.

Cartoni

LAMBDA 25

The Talon Jr. is a lightweight 2-axis head with a compact design.

VariZoom

TALON JR

Our equipment is offered for daily, weekly or run-of-show rentals. We’re happy to teach anyone how to use the gear and look forward to sharing our experience! Feel free to reach out and we can help you find the right tool for your production. We’re excited to help you bring your project to life.
